Deep Conical

The Deep Conical (DC) dental implant system offers practitioners a dental implant with state-of-the-art design, featuring the proven internal cone connection system, for treatment of the full range of clinical indications.

Innovation

The DC implant features an 11° internal conical connection system with a double internal hex anti-rotation feature, providing a tight implant-abutment seal and superior implant-abutment rigidity, without inducing abutment seating height variance.

Combined with state-of-the-art design features such as microthreads on the neck, a built-in platform shift, highly effective self-tapping thread, and the Southern Implants moderately rough Alumina blasted surface (with over 20 years of proven clinical success), the risk of adverse implant reactions such as soft tissue irritation, implant mobility, bone loss and peri-implantitis is reduced. The option of tapered, cylindrical and Co-Axis™ (angulated platform) body shapes offer practitioners a versatile and trustworthy tool for effective treatment of the full range of indications, bone quality and anatomical presentations.

Surgical and Prosthetic Benefits

  • Excellent tactile sensibility during placement
  • High stability restorations
  • Fast insertion and excellent primary stability due to double-start thread
  • State-of-the-art design features to minimize risk of peri-implant complications
  • Wide range of prosthetic options for treatment of single tooth, partial or full edentulism

Technical Facts

  • Available in 3.0mm, 3.5mm, 4.0mm and 5.0mm implant diameters
  • Tapered or cylindrical body shape
  • Lengths of 6.1-15mm
  • Moderately rough surface with 20 years of clinical evidence
  • Available in 3.5mm and 4.0mm and 5.0mm diameter Co-Axis™ (angulated platform) configurations
  • Smaller implants made from higher strength cold-worked titanium

For more information on the DC implant, please contact us
